Mechanical | Dimensions: | |
| 164 mm x 73 mm x 24.5 mm (6.5 in x 2.9 in | ||
| x 1.0 in) | ||
| Weight: 300g (10.6 oz) with battery | ||
| Display: 10.6 cm (4-inch) | ||
| Resolution: WVGA 480 x 800 | ||
| Type: Transmissive | ||
| Backlight: LED | ||
| Touchscreen: Multi-touch capacitive | ||
| Keyboard: 26-key numeric main keypad; | ||
| side keys: volume up/down, right and left | ||
| scan keys; soft keys: 3 touch keys (Back, | ||
| Home, Menu) | ||
ENVIRONMENTAL | Operating Temperature: | |
| -10°C to +50°C (14°F to 122°F) | ||
| Storage Temperature: | ||
| -20°C to +60°C (-4°F to +148°F) | ||
| Humidity: 10% to 90% (non-condensing) | ||
| Drop: 1.5m MIL drop cross operation | ||
| temperature | ||
| Electrostatic Discharge (ESD): | ||
| ±8 kV direct; ±12 kV air | ||
| Environmental Sealing: IP65 | ||
| Vibration: Vertical rms = 1.04 g, Transverse; | ||
| rms = 0.2 g, Longitudinal rms = 0.74 g | ||
PERFORMANCE | Processor: Qualcomm 1.8 GHz octa-core | |
| Memory: 3G/32G, 4G/64G Optional | ||
| Operating System: Android 10 with Google | ||
| Mobile Services | ||
| Expansion Memory: MicroSDHC (up to 128 | ||
| GB) | ||
| PC Communication: Type-C USB2.0 | ||
| Battery: 4000 mAh @ 3.8 V | ||
| Camera: 13-megapixel color camera with | ||
| autofocus and LED flash | ||
| GPS: GNSS Receiver for GPS, GLONASS and | ||
| Compass (Beidou) (for WWAN only) | ||
| Button Batteries: 22 mF super-cap | ||
| Real-Time Clock: 10-min backup via super- | ||
| cap | ||
| Charging Time: 4 hours | ||
| Battery Runtime: 12 hours+ | ||
| Engine: 1D/2D: S0703, N3603 optional | ||
| LEDs: | ||
| Battery Condition: Red/Green/Blue | ||
| Scan Indication: Red/Green light | ||
| Vibration: Vibration Motor | ||
| Sensors: Proximity, Light, Acceleration | ||
WIRELESS CONNECTIVITY | WLAN: IEEE 802.11 a/b/g/n/ac radio, Wi-Fi | |
| certified 802.11 a/b/g/n/ac | ||
| WLAN Security: Open, WEP, WPA/WPA2- | ||
| PSK, PEAP, EAP-TLS, EAP-TTLS, EAP- | ||
| PWD,EAP-SIM,EAP-AKA | ||
| WWAN* | ||
| GSM & EDGE: Band2/3/ 5/8 | ||
| WCDMA: Band1/2/4/5/ 6/8/ 9/ 19 | ||
| FDD-LTE: Band1/ 2/ 3/ 4/ 5/ 7/ 8/ 9/ 12/ | ||
| 13/ 17/19/20/ 25/ 26/ 28/30/66 | ||
| TDD-LTE: Band38/39/40/41(2555~2655) | ||
| Bluetooth: Bluetooth® Class 4.2 | ||
| NFC: Integrated Near Field Communication | ||
ACCESSORIES (STANDARD) | USB Communication Cable: Type-C USB | |
| 2.0, (communicates to PC, supports | ||
| adapter/USB charging) | ||
| Wall Adapter | ||
ACCESSORIES (OPTIONAL) | Hand Strap | |
| Replacement Battery | ||
| Single Charging Cradle: for 1x terminal | ||
| charging | ||
| Quad Battery Charger: for 4x batteries | ||
| charging | ||
| USB Wall Adapter: 5V/2A | ||
| WARRANTY | One-year factory warranty |
