Print |
Print Method:Â Direct Thermal |
Print Speed:Â 250mm/s |
Print Resolution:Â 180 dpi (7dots/mm) |
Print Width:Â 54mm, 74mm |
Print Font |
Character Size:Â Font A 12 x 24 dots, Font B 9 x 17 dots, Font C 9 x 24 dots |
Character per Line:Â Font A 42, Font B 56, Font C 56 |
Character Sets:Â Alphanumeric: 95 ã…£ Extended Graphics: 128 x 37 Page ã…£ International: 32 |
Barcode Types:1D – Coda Bar, Code39, Code93, Code128, EAN-8, EAN-13, ITF, UPC-A, UPC-E ㅣ 2D – PDF417, QR Code |
Graphics:Â Supporting User-defined Fonts, Graphics, Formats, Logos |
Media |
Type:Â Thermal Roll Paper |
Paper Feed:Â Friction Feed |
Loading:Â Drop in |
Width:Â 58mm, 80mm |
Roll Diameter:Â Max. 83mm |
Thickness: 62~75μm |
Auto Cutter:Â Full or Partial Selectable |
Partition:Â 2 inch (58mm) |
Reliability |
MCBF:Â 60million Lines |
TPH:Â 150km |
Auto Cutter:Â 1.5million Cuts |
General |
Interface:Â Built-in USB + Serial(RJ-45) + Ethernet (Option : WiFi, Bluetooth, Gender Type) |
Suppport Mobile Operating Systems:Â Android, iOS (SDK) |
Receive Buffer:Â 4kb |
Printer Driver:Â Windows Driver, OPOS Driver, JPOS Driver, Linux CUPS Driver, Mac Driver, Virtual COM USB/Ethernet Driver, Utility Program |
Utility:Â Unified POS Utility(VMSM,NV) |
Sensors:Â Paper End, Cover Open, Black Mark, Partition |
Drawer:Â 2 Port (via Y-Type Adaptor) |
Power Supply:Â 24V, 2.5A |
Temperature & Humidity: Operating: 0 ~ 45ºC, 10 ~ 80% RH (No condensations) ㅣ Storage : -20 ~ 60ºC, 10 ~ 90% RH (No condensations) |
Safety Standards:Â CE, FCC |
Dimensions(W x D x H):Â 142 x 145 x195(mm), 5.6 x 5.7 x 7.7(in) |
Packing Dimensions(W x H x D):Â 261 x 290 x 205 (mm), 10.23 x 11.41 x 8.07 (in) |
Weight:Â 1,600g, 3.5lbs |
Color:Â Black |
Options:Â Ethernet, Bluetooth, WiFi (Interface Card Type) |
Eco: WEEE, RoHS, Reach SVHC, Energy Star® |
Warranty: 2 Years |
What’s in the Box: A11, Power Supply(Adapter, Power Cord), USB+ Serial Cable, Paper Roll(30Ø), Partition, Installation CD, Installation Guide |
