Print |
Print Method: Direct Thermal |
Print Speed: 250mm/s |
Print Resolution: 203.2 dpi (8dots/mm) |
Print Width: 72mm |
Print Font |
Character Size: Font A 13 x 26 dots, Font B 10 x 20 dots, Extra Font 12×24 dots |
Character per Line: Font A 42, Font B 56, Extra Font A 48 |
Character Sets: Alphanumeric: 95 ㅣ Extended Graphics: 128 x 37 Page ㅣ International: 32 ㅣ Unicode: UTF-8 |
Barcode Types: 1D : Coda Bar, Code39, Code93, Code128, EAN-8, EAN-13, ITF, UPC-A, UPC-E ㅣ 2D : PDF417, QR Code |
Graphics: Supporting User-defined Fonts, Graphics, Logos |
Media |
Type: Thermal Roll Paper |
Paper Feed: Friction Feed |
Loading: Drop in |
Width: 58mm, 80mm |
Roll Diameter: Max. 83mm |
Thickness: 70μm |
Auto Cutter: Full or Partial Selectable |
Partition: 2 inch (58mm) (Option) |
Reliability |
MCBF: 60million Lines |
TPH: 150km |
Auto Cutter: 1.5million Cuts |
General |
Interface: Prime Model : Serial + USB + Ethernet + (Option : WiFi/Bluetooth) ㅣ Standard Model : Serial + USB + (Option : WiFi/Bluetooth) |
Suppport Mobile Operating Systems: Android, iOS (SDK) |
Receive Buffer: 4kb |
Printer Driver: Windows / OPOS / JPOS Driver, Linux CUPS Driver, Virtual COM USB Driver, Utility Program |
Utility: NV Image Uploader, Firmware Down loader, Network Configuration Tool |
Sensors: Paper End, Cover Open |
Drawer: 2 Port (via Y-Type Adaptor) |
Power Supply: 24V, 2.5A |
Temperature & Humidity: Operating: 0 ~ 45ºC, 10 ~ 80% RH (No condensations) ㅣ Storage : -20 ~ 60ºC, 10 ~ 90% RH (No condensations) |
Safety Standards: CE, FCC |
Dimensions(W x D x H): 130 x 129 x 130.2 (mm), 5.1 x 5.07 x 5.1 (in) |
Packing Dimensions(W x D x H): 260 x 290 x 205 (mm), 10.23 x 11.41 x 8.07 (in) |
Weight: Prime Model : 752g, 1.65lbs, Standard Model : 746g, 1.64lbs |
Packing Weight: 2.45kg, 5.40lbs |
Color: Dark Grey |
Options: WiFi+Bluetooth Combo module |
Wall Mount Kit: Yes (Option) |
Eco: RoHS |
Warranty: 2 Years |
What’s in the Box: A8, Power Supply(Adapter, Power Cord), Paper Roll(30Ø), Installation Guide, USB Cable, Serial Cable (Option) |
