Printer Specifications | Printing method: Direct Thermal | |
| Printing speed: SLP-DX220: Up to 6 ips (152 mm/sec) SLP-DX223: Up to 4 ips (100 mm/sec) | ||
| Print Resolution: SLP-DX220: 203 dpi SLP-DX223: 300 dpi | ||
| Print Width: SLP-DX220: Up to 54 mm SLP-DX223: Up to 56.9 mm | ||
| Print Length: Up to 2,000 mm | ||
| Sensor: Transmissive, Reflective (Adjustable), Head open | ||
Media Charateristics | Media Type: Gap, Black Mark, Notch, Continuous, Fan-Fold | |
| Media Width: 15 ~ 60 mm | ||
| Media Roll Diameter: Up to 130 mm | ||
| Media Thickness: 0.06 ~ 0.20 mm | ||
| Supply Method: Easy Paper Loading | ||
| Inner Core: 12.5 ~ 38.1mm | ||
Physical Characteristics | Dimensions (WxDxH): 120 x 230 x 170 mm (4.72 x 9.05 x 6.69 inch) | |
| Weight: 1.36 kg (2.99 lbs.) | ||
| Electrical: EnergyStar Certified, External Power Adaptor 100-240V AC, 50/60Hz | ||
Performance Characteristics | Memory: 64 MB SDRAM, 128 MB Flash | |
| Interface: Interface Standard: USB + Serial Optional: ① USB + Ethernet + WLAN¹ ② USB + WLAN* + Bluetooth² —————————————————————– WLAN¹: 802.11a/b/g/n/ac USB dongle type (Optional) Bluetooth²: Built-in type, MFi iAP2 certified | ||
Operating & Environment Characteristics | Temperature: Operating: 0 ~ 40℃ (32 ~ 104℉) Storage: -20 ~ 60℃ (-4 ~ 140℉) | |
| Humidity: Operating: 10 ~ 80% RH Storage: 10 ~ 90% RH | ||
Software | Emulation: SLCS™, BPL-Z™ (ZPLII), BPL-E™ (EPL) | |
| Driver / Utility: Windows Driver (Europlus / Seagull), Linux / Mac CUPS Driver, Virtual COM USB / Ethernet Driver, Utility Program, OPOS / JPOS Driver, Bartender Ultralite for BIXOLON, Label Artist-II™ | ||
| SDK / Plugin: Android / iOS / Windows SDK, Linux SDK, Chrome SDK, Xamarin SDK | ||
| Application: Label Artist™ Mobile (Android, iOS), mPrint App (iOS), mPrint Server (Windows, iOS) | ||
| MDM: BIXOLON Profile Manager – XPM™, XCM™ (Windows, Android) | ||
Fonts / Graphics / Symbologies | Fonts: 10 SLCS™ / One SLCS™ / 16 BPL-Z™ / One BPL-Z™ / 5 BPL-E™ / 23 Code Page / Unicode supported (UTF-8, UTF-16LE, UTF-16BE) | |
| Graphics: Supporting user-defined fonts, graphics, formats, and logos | ||
| Barcode Symbologies: 1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB 2D: Aztec, Codablock, Code49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code, TLC39 | ||
| Options | Peeler, Auto Cutter, WLAN Dongle (Consensus required) |
