Shuttle SG-15 Price Verifier

The QubePos Shuttle SG-15 is an entry-level, small and attractive price verifier that features the latest technology and interfacing through Wireless RF or hard-wired Ethernet. Depending on the font set, the bright display has 3 or 5 lines and can display up to 20 characters per line. The Shuttle SG-15 can be installed anywhere in a store, including on the shelves.

Display: 3.5″ colour display
Self-Detection and Configuration of Scan-Engine
Standby Scheduler for Sustainable Use
Scanner Options: Laser Omni, CCD Single Line, 2D imager
Interface Options: Ethernet, Power over Ethernet (PoE), WIFI
Configuration: Standard Web Browser

SKU: 204200-1 Category: Scanner Tag: Retail

System Architecture	Processor: ARM Cortex-A7 Dual-Core
	Operating Platform: Standard Linux (Kernel > 3.0)
	Memory Flash: 2GB, expandable with USB fl ash drive and SD card
	Memory RAM: 512MB
	Software: Client applications included
Output Media	Display: 3.5’’ diagonal
	Brightness: 450 cd/m2 16 million colors for high quality displaying
	Resolution: 320 x 240 pixels
	Graphics Supported: PNG, JPEG, GIF, BMP
	Audio: 1 Speaker
	Data Ports: 1x USB 2.0; 1x LAN port 10/100MB; Power Over Ethernet (Optional)
Network Interface	LAN: 100MB Base-TX/10MB Base-T(802.3) standard on board Power over Ethernet IEEE 802.af optional
	Wireless LAN: 802.11 a/b/ c/ g/n 2.4GHz or 5 GHz
	Protocols: WPA, PSK and WPA Enterprise security
Physical & Environmental	Dimensions (H x W x D): 182 x 131 x 95 mm (7.17 x 5.16 x 3.74 inch)
	Mounting Options: Wall mount with 2 screws
	Weight: < 0.9 kg
	Power Supply: +5V/2A PSU or Power over Ethernet (IEEE802.3af)
	Power Consumption: 3-5 Watt (5VDC, 580~1050mA) Depending on interface and scanner type
	Operating Temperature: 0°~40°C
	Storage Temperature: -20°~60°C
	Humidity: 5%~95% RH (non-condensing)
Regulatory	Regulatory: CE, FCC and RoHs compliant
