| Physical Characteristics | ||
Dimensions | 7.89 in. L x 2.76 in. W x 1.52 in. D | |
| 200.5 mm L x 70 mm W x 38.5 mm D | ||
Weight | Standard battery: 10.4 oz./296 g | |
| Extended battery: 11.2 oz./316 g | ||
| Display | 4 in. WVGA (800 x 480), LED backlight; color display; | |
| optically bonded to touch panel | ||
| Touch Panel | Capacitive touch panel; multi-touch; Corning® Gorilla® Glass | |
| Power | Standard capacity 3500 mAh/12.60 Wh | |
| Extended capacity 4900 mAh/17.64 Wh | ||
| Imager Window | Corning® Gorilla® Glass | |
| Expansion Slot | User accessible MicroSD slot up to 128 GB SDXC | |
| SIM | One Nano SIM slot; optional eSIM (MC2700 only) | |
| Notifications | Audible tone; multi-color LEDs; haptic feedback (China SKU only) | |
| Keypad | 34 key Numeric with FN keys; supports on-screen keypad | |
| Voice and Audio | Internal speaker and microphone; Bluetooth wireless headset support; high quality speaker phone | |
| Buttons | Physical scan, volume up/down; power | |
Network Connections | MC2200/MC2700: WLAN (Wi-Fi), WPAN (Bluetooth), | |
| USB 2.0 High Speed (Host and Client) | ||
| MC2700 only: WWAN (cellular) | ||
| Performance Characteristics | ||
| CPU | Qualcomm SnapdragonTM 660 octa-core, 1.8 GHz | |
Operating System | MC2200: Android 11; upgradeable to Android 14 | |
| MC2700: Android 11; upgradeable to Android 14 | ||
| Android Enterprise | Google AER Certified | |
| Recommended (AER) | ||
| Memory | 2 GB RAM/16 GB Flash memory | |
| 3 GB RAM/32 GB Flash memory | ||
Security | Product is FIPS 140-2 validated. This security feature | |
| can be enabled on select configurations through a | ||
| custom SKU request. Product supports Secure Boot, | ||
| Verified Boot | ||
| User Environment | ||
| Operating Temp. | -4° F to 122° F/-20° C to 50° C | |
| Storage Temp. | -40° F to 158° F/-40° C to 70° C | |
| Humidity | 5%-95% non condensing | |
Drop Spec. | Multiple 5 ft./1.52 m drop to concrete from 14° F to | |
| 122° F/-10° C to 50° C per MIL-STD 810G | ||
Tumble Spec. | 500 1.6 ft./0.5 m tumbles; meets and exceeds IEC | |
| tumble specifications | ||
| Sealing | IP65 per applicable IEC sealing specifications | |
Vibration | 4g’s PK Sine (5Hz to 2kHz); 0.04g 2/Hz Random (20 | |
| Hz to 2 kHz); 60 minutes duration per axis, 3 axis | ||
| Scanner Window | Corning® Gorilla® Glass | |
| Electrostatic | _+/-15 kV air discharge, +/-8 kV direct/indirect | |
| Discharge (ESD) | discharge | |
| Interactive Sensor Technology (IST) | ||
| Motion Sensor | 3-axis accelerometer with MEMS Gyro | |
| Scanning | SE4100 1D/2D standard range imager | |
| Camera | Optional rear camera 13 MP Phase Detection Auto | |
| Focus, with Flash LED | ||
| NFC | ISO14443 Type A and B: FeliCa and ISO 15693 cards. | |
| P2P mode and Card Emulation via Host (HCE) support | ||
| Wireless WAN, Data Communications Only | ||
Radio Frequency Band | MC2700 North America | |
| • UMTS: B2/B4/B5 | ||
| • LTE: B2/B4/B5/B7/B12/B13/B14/B17/B66 | ||
| • LTE: Category 6 | ||
| MC2700 Rest of World | ||
| • GSM: 850/900/1800/1900 | ||
| • UMTS: B1/B2/B3/B4/B5/B8/B9/B19 | ||
| • LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B19/B20/B28 | ||
| • LTE-TDD: B38//B40/B41 | ||
| • LTE: Category 6 | ||
| MC2700 China | ||
| • GSM: 850/900/1800 | ||
| • UMTS: B1/B5/B8 | ||
| • LTE-FDD: B1/B3/B5/B7/B8 | ||
| • LTE-TDD: B38/B39/B40/B41 | ||
| • LTE: Category 6 | ||
VoIP Communications | Optional Workforce Connect Voice3 | |
| turns MC2200/ | ||
| MC2700 devices into fully-featured PBX handsets | ||
| with a custom interface that makes it easy to | ||
| execute even the most complex telephony features | ||
| — eliminating the need to purchase and manage | ||
| additional voice-enabled devices. | ||
GPS | MC2700 only: Autonomous, Concurrent GPS; | |
| GLONASS; Gallileo; BeiDou, and A-GPS. Supports | ||
| IZAT (TM) XTRA | ||
| Wireless LAN | ||
WLAN Radio | IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v; Wi-Fi certified; | |
| IPv4, IPv6, 1×1 MU-MIMO | ||
Data Rates | 2.4 GHz: 802.11b/g/n — 20 MHz, 40 MHz — up to | |
| 150 Mbps | ||
| 5 GHz: 802.11a/g/n/ac – 20 MHz, 40 MHz, 80 MHz – | ||
| up to 433 Mbp | ||
Operating Channels | Channel 1-13 (2412-2472 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9, | |
| 10, 11, 12, 13 | ||
| Channel 36-165 (5180-5825MHz): 36, 40, 44, 48, | ||
| 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, | ||
| 132, 136, 140, 144, 149, 153, 157, 161, 165 | ||
| Channel bandwidth: 20, 40, 80 MHz | ||
| Actual operating channels/frequencies and | ||
| bandwidths depend on regulatory rules and | ||
| certification agency | ||
Security and Encryption | WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and | |
| AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise | ||
| (TKIP and AES); WPA3 Enterprise (AES) | ||
| EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS, | ||
| PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP and | ||
| EAP-PWD; WPA3 Enterprise 192-bit Mode (GCMP-256) | ||
| EAP-TLS; Enhanced Open (OWE) | ||
Certifications | WFA (802.11n, WPA2-Personal, WPA3-Personal, | |
| WPA2-Enterprise, WPA3-Enterprise) | ||
Fast Roam | 802.11r (Over-The-Air); PMKID caching; Cisco CCKM; | |
| OKC | ||
| Bluetooth | Class 2, Bluetooth V5.0 with BR/EDR and Bluetooth | |
| Low Energy (BLE) support | ||
Environmental Compliance | • RoHS Directive 2011/65/EU; Amendment 2015/863 | |
| • REACH SVHC 1907/2006 | ||
Mobility DNA Professional Integrated Solutions | DataWedge; Device Diagnostics; EMDK; Enterprise Home Screen; Mx Extensions; | |
| StageNow | ||
Mobility DNA | Mobility DNA solutions help you get more value out of our mobile computers | |
| by adding functionality as well as simplifying deployment and management of | ||
| our mobile devices. For more information on these Zebra-only features, of our | ||
| mobile devices. For more information on these Zebra-only features, of our mobile | ||
| devices. | ||
Warranty | Subject to the terms of Zebra’s hardware warranty statement, the MC2200/ | |
| MC2700 devices are warranted against defects in workmanship and materials | ||
| for a period of one (1) year from the date of shipment. | ||
