Zebra TC72 Mobile Handheld Computer

The ultimate in ultra-rugged enterprise-class all-touch computing. At the edge of your business are your front line workers that spend their days face-to-face serving the important asset in your company — your customers. Now, there’s a device designed to take customer service to the next level by delivering everything your workers need to achieve peak efficiency, with trouble-free reliability — the TC72 Android Touch Computers.

  • Complete cellular network flexibility with single device simplicity
  • Advanced touchscreen technology
  • Bluetooth 5.0 for twice the speed and four times the range
  • Maximize productivity with enterprise accessories
  • Improve device value with Zebra’s optional VisibilityIQTM Services
  • New 5 MP front-facing camera supports more advanced apps



SKU: 204025 Category: Tag:
Physical Characteristics

Dimensions
 7.89 in. L x 2.76 in. W x 1.52 in. D
 200.5 mm L x 70 mm W x 38.5 mm D


Weight
 Standard battery: 10.4 oz./296 g
 Extended battery: 11.2 oz./316 g

Display 4 in. WVGA (800 x 480), LED backlight; color display;
  optically bonded to touch panel

Touch Panel Capacitive touch panel; multi-touch; Corning® Gorilla® Glass

Power Standard capacity 3500 mAh/12.60 Wh
  Extended capacity 4900 mAh/17.64 Wh

Imager Window Corning® Gorilla® Glass

Expansion Slot User accessible MicroSD slot up to 128 GB SDXC

SIM One Nano SIM slot; optional eSIM (MC2700 only)

Notifications Audible tone; multi-color LEDs; haptic feedback (China SKU only)

Keypad 34 key Numeric with FN keys; supports on-screen keypad

Voice and Audio
Internal speaker and microphone; Bluetooth wireless headset support; high quality speaker phone

Buttons Physical scan, volume up/down; power

Network Connections
 MC2200/MC2700: WLAN (Wi-Fi), WPAN (Bluetooth),
 USB 2.0 High Speed (Host and Client)
 MC2700 only: WWAN (cellular)

Performance Characteristics
CPU Qualcomm SnapdragonTM 660 octa-core, 1.8 GHz

Operating System
 MC2200: Android 11; upgradeable to Android 14
 MC2700: Android 11; upgradeable to Android 14

Android Enterprise Google AER Certified
Recommended (AER)

Memory 2 GB RAM/16 GB Flash memory
  3 GB RAM/32 GB Flash memory

Security
 Product is FIPS 140-2 validated. This security feature
 can be enabled on select configurations through a
 custom SKU request. Product supports Secure Boot,
 Verified Boot

User Environment
Operating Temp. -4° F to 122° F/-20° C to 50° C

Storage Temp. -40° F to 158° F/-40° C to 70° C

Humidity 5%-95% non condensing

Drop Spec.
 Multiple 5 ft./1.52 m drop to concrete from 14° F to
 122° F/-10° C to 50° C per MIL-STD 810G

Tumble Spec.
 500 1.6 ft./0.5 m tumbles; meets and exceeds IEC
 tumble specifications

Sealing IP65 per applicable IEC sealing specifications

Vibration
 4g’s PK Sine (5Hz to 2kHz); 0.04g 2/Hz Random (20
 Hz to 2 kHz); 60 minutes duration per axis, 3 axis

Scanner Window Corning® Gorilla® Glass

Electrostatic _+/-15 kV air discharge, +/-8 kV direct/indirect
Discharge (ESD) discharge

Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer with MEMS Gyro

Scanning SE4100 1D/2D standard range imager

Camera Optional rear camera 13 MP Phase Detection Auto
  Focus, with Flash LED

NFC ISO14443 Type A and B: FeliCa and ISO 15693 cards.
  P2P mode and Card Emulation via Host (HCE) support

Wireless WAN, Data Communications Only
Radio Frequency Band
 MC2700 North America
 • UMTS: B2/B4/B5
 • LTE: B2/B4/B5/B7/B12/B13/B14/B17/B66
 • LTE: Category 6
 MC2700 Rest of World
 • GSM: 850/900/1800/1900
 • UMTS: B1/B2/B3/B4/B5/B8/B9/B19
 • LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B19/B20/B28
 • LTE-TDD: B38//B40/B41
 • LTE: Category 6
 MC2700 China
 • GSM: 850/900/1800
 • UMTS: B1/B5/B8
 • LTE-FDD: B1/B3/B5/B7/B8
 • LTE-TDD: B38/B39/B40/B41
 • LTE: Category 6

VoIP Communications
 Optional Workforce Connect Voice3
 turns MC2200/
 MC2700 devices into fully-featured PBX handsets
 with a custom interface that makes it easy to
 execute even the most complex telephony features
 — eliminating the need to purchase and manage
 additional voice-enabled devices.

GPS
 MC2700 only: Autonomous, Concurrent GPS;
 GLONASS; Gallileo; BeiDou, and A-GPS. Supports
 IZAT (TM) XTRA

Wireless LAN
WLAN Radio
 IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v; Wi-Fi certified;
 IPv4, IPv6, 1×1 MU-MIMO

Data Rates
 2.4 GHz: 802.11b/g/n — 20 MHz, 40 MHz — up to
 150 Mbps
 5 GHz: 802.11a/g/n/ac – 20 MHz, 40 MHz, 80 MHz –
 up to 433 Mbp

Operating Channels
 Channel 1-13 (2412-2472 MHz): 1, 2, 3, 4, 5, 6, 7, 8, 9,
 10, 11, 12, 13
 Channel 36-165 (5180-5825MHz): 36, 40, 44, 48,
 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128,
 132, 136, 140, 144, 149, 153, 157, 161, 165
 Channel bandwidth: 20, 40, 80 MHz
 Actual operating channels/frequencies and
 bandwidths depend on regulatory rules and
 certification agency

Security and Encryption
 WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and
 AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise
 (TKIP and AES); WPA3 Enterprise (AES)
 EAP-TTLS (PAP, MSCHAP, MSCHAPv2), EAP-TLS,
 PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP and
 EAP-PWD; WPA3 Enterprise 192-bit Mode (GCMP-256)
 EAP-TLS; Enhanced Open (OWE)

Certifications
 WFA (802.11n, WPA2-Personal, WPA3-Personal,
 WPA2-Enterprise, WPA3-Enterprise)

Fast Roam
 802.11r (Over-The-Air); PMKID caching; Cisco CCKM;
 OKC

Bluetooth Class 2, Bluetooth V5.0 with BR/EDR and Bluetooth
  Low Energy (BLE) support

Environmental Compliance
 • RoHS Directive 2011/65/EU; Amendment 2015/863
 • REACH SVHC 1907/2006

Mobility DNA Professional Integrated Solutions
 DataWedge; Device Diagnostics; EMDK; Enterprise Home Screen; Mx Extensions;
 StageNow

Mobility DNA
 Mobility DNA solutions help you get more value out of our mobile computers
 by adding functionality as well as simplifying deployment and management of
 our mobile devices. For more information on these Zebra-only features, of our
 mobile devices. For more information on these Zebra-only features, of our mobile
 devices.

Warranty
 Subject to the terms of Zebra’s hardware warranty statement, the MC2200/
 MC2700 devices are warranted against defects in workmanship and materials
 for a period of one (1) year from the date of shipment.



Weight 376 g
Dimensions 161 × 84 × 28 mm
