ACT1560 POS Terminal

ACT implies a POS terminal with high reliability that boasts a slim and edgy design with a 15.6″ widescreen. ACT is a GMS-certified, Android-based POS with the latest Android 12 with SOTI certification, a mobile device management solution allowing secure and efficient device management.

  • Lightweight and fast Android platform adoption(RK3399)
  • Ultra slim and wide LCD panel
  • Android 12(Snow Cone) support (GMSCertified)
  • Bright and clear 15.6” widescreen, precise touch PCAP touch
  • Supports stand-and-wall mount flexible installation
  • Provided ample I/O ports for connecting various peripherals devices
  • Second display support with touch function (optional)
SKU: 203066 Category: Tags: ,
 Processors: RK3399
Dual-core Cortex-A72 up to 1.8GHz
Quad-core Cortex-A53 up to 1.4GHz
 Memory: 4GB Standard, DDR4, On-board
 Storage: eMMC 32GB, On-board (Max. 256GB)
 Operating Systems: Android 12
 Audio: HD Audio Codec
 Type: 15.6″ TFT LCD, LED Backlight (eDP Interface), Projected Capacitive Touch
 Resolution: 1920 x 1080
 Brightness: 300 cd/m²
 Display: 1 x Displayport, MiniDP (Only compatible with ACT-only products)
 USB: Rear 5 (4 x USB 2.0, 1 x USB-C)
 Serial: External 2
COM1 RJ45 , Full Signal
COM3 MiniDP, Only TX/RX, 12V Power Output, Reserved for CDP
Internal 1
COM2 FPC Connector , Only TX/RX, Reserved for MSR
 CashDrawer Port: 1 x CashDrawer Port (RJ-12, 6 Pins(GPIO Communication))
 WIFI / BT: BT(V4.0)+ WLAN (802.11 a/b/g/n, 2.4G/5G) combo module,
On-board (Factory Option)
 Lan: 1 x Gigabit Ethernet , RJ-45
 Audio & Speaker: 1 x Line-out / 1W (Mono)
 Power DC-IN: 4 Pin DIN Jack
Power Power Supply: Adapter 12V, 5A(4 Pin Din Jack)
Options & Peripherals
 2nd Displays: 10.1” (1280 x 800) LCD Display, Optional Touchscreen
 External IO Box: Option 1 : 2 x 12V Powered USB 2.0 / 1 x 24V Powered USB 2.0 / 2 x RJ45 (Full Signal)
Option 2 : 1 x 12V Powered USB 2.0 / 1 x 24V Powered USB 2.0 / 2 x USB 2.0 / 2 x RJ45 (Full Signal)
Option 3 : 1 x 24V Powered USB 2.0 / 4 x USB 2.0 / 2 x RJ45 (Full Signal)
Option 4 : 6 x USB 2.0 / 2 x RJ45 (Full Signal)
One option attachable at a time
 Wall Mount Kit: TBD
 Conversion Cable: RJ-45 to D-sub 9
