MECHANICAL/ELECTRICAL | Dimensions: (L × W × H): 62 mm x 169 mm x 82 mm (2.4 in x 6.6 in x 3.2 in) | |
Scanner Weight: 130 g (4.6 oz) | ||
Input voltage: 4.0V DC to 5.5V DC | ||
Operating Power: 2 W (400 mA @ 5V DC) | ||
Standby Power: 0.45 W (90 mA @ 5V DC) | ||
Host System Interfaces: USB, Keyboard Wedge, RS-232, RS485 support for IBM 46xx (RS485) | ||
ENVIRONMENTAL | Operating temperature: 0°C to 50°C (32°F to 122°F) | |
Storage temperature: -40°C to 60°C (-40°F to 140°F) | ||
Electrostatic Discharge (ESD) (Scanners and Cradles): ±8 kV indirect coupling plane, ±15 kV direct air | ||
Humidity: 0% to 95% relative humidity, non-condensing | ||
Tumble Spec: 1,000 0.5 m (1.6 ft) tumbles (impacts) | ||
Drop: Engineered to withstand 30 1.8 m (6 ft) drops to concrete | ||
Environmental Sealing: IP52 | ||
Light Levels: 0 to 100,000 lux (9,290 foot-candles) | ||
SCANNING PERFORMANCE | Scan Pattern: Area Image (1040 x 720 pixel array) | |
Motion tolerance: 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus | ||
Scan angle: Horizontal: 39.2° nominal; Vertical: 27.4° nominal | ||
Roll, Pitch, Skew: ±180°, ±65°, ±70° | ||
Print Contrast: 20% | ||
Decode Capability: Reads standard 1D, PDF, 2D, and DotCode symbologies | ||
Note: Decode capabilities dependent on configuration | ||
WARRANTY | Warranty: 5-year factory warranty |
