Performance Characteristics | Optical System: High performance linear imaging engine | |
| Print Contrast: 20% minimum reflective difference | ||
| Light Source: 630nm LED | ||
| Minimum Resolution: 3 mil (Code 39, PCS 0.9) | ||
| Reading Range: *1 13 mil (0.33mm) UPC/EAN More than 13” 20 mil (0.5mm) Code 39 up to 18” | ||
| Scan Rate: Dynamic scanning rate up to 500 scans per second | ||
| Reading Direction: Bi-directional (forward and backward) | ||
| Pitch / Skew / Tilt: ±65 ̊ / ± 65 ̊ / ± 55 ̊ | ||
| Host Interfaces: USB HID (USB Keyboard) USB VCOM (USB COM port emulation) Standard RS232 | ||
| Configuration Setup: Command barcodes iCode FuzzyScan PowerTool | ||
| Data Editing: DataWizard Premium | ||
Physical Characteristics | Dimensions: 165.0 mm (L) x 64.7 mm (W) x 38.7 mm (D) 6.50 in. (L) x 2.55 in. (W) x 1.52 in. (D) | |
| Weight: 106g (cable excluded) | ||
| Color: Light Gray or Black | ||
| User Interfaces: Blue LED indications Programmable beeper Optional vibrator | ||
| Operating Voltage: 5VDC ± 10% | ||
| Operating Current: Operating : Typical 170 mA @5VDC Standby : Typical 75 mA @5VDC | ||
| Supported Symbologies | 1D Linear Codes: Code 39, Code 39 Full ASCII, Code 32, Code 39 Trioptic Code 128, GS1-128, Codabar, Code 11, Code 93 Standard & Industrial 2 of 5, Interleaved & Matrix 2 of 5 German Postal Code, China Postal Code, IATA UPC/EAN/JAN, UPC/EAN/JAN with Addendum Telepen, MSI/Plessey & UK/Plessey GS1 DataBar (formerly RSS) Linear & Linear Stacked | |
| Linear-stacked: PDF417, Micro PDF417, Codablock F, Composite | ||
User Environment | Drop Specifications: Withstand multiple 1.6m/5.2ft. drops to concrete | |
| Environmental Sealing: IP41 | ||
| Operating Temperature: -10 ̊C to 50 ̊C (14 ̊F to 122 ̊F) | ||
| Storage Temperature: -40 ̊C to 70 ̊C (-40 ̊F to 158 ̊F) | ||
| Humidity: 5% to 95% relative humidity, non-condensing | ||
| Ambient Light Immunity: 0 ~ 80,000 lux | ||
| ESD Protection: Functional after 15KV discharge | ||
Safety & Regulatory | EMC: CE, FCC, BSMI, RCM, KC, VCCI | |
| Safety *2: LED Eye Safety IEC62471, Exempt Group | ||
| Environmental: Compliant with RoHS directive | ||
Accessories | Cables: RS232 Serial Cable USB Cable USB Power Supply Cable | |
| Others: US100 SmartStand US50 Hands-free Stand Universal Holder |
