MECHANICAL | Dimensions: (L × W × H): 60 mm x 168 mm x 74 mm (2.3” x 6.6” x 2.9”) | |
| Weight: 133 g (4.7 oz) | ||
ELECTRICAL | Input voltage: 5 V ± 5% | |
| Operating Power: 700 mW; 140 mA (typical) @5V | ||
| Standby Power: 425 mW; 85 mA (typical) @ 5V | ||
| Host System Interfaces: Multi-interface; includes USB (HID Keyboard, Serial, IBM OEM), RS232 (TTL + 5V, 4 signals), Keyboard Wedge, RS-232C (± 12V), IBM RS485 supported via adapter cable | ||
ENVIRONMENTAL | Operating temperature: 0°C to 40°C (32°F to 104°F) | |
| Storage temperature: -20°C to 60°C (-4°F to 140°F) | ||
| Humidity: 5% to 95% relative humidity, non-condensing | ||
| Drop: Designed to withstand 30 drops on concrete from 1.5 m (5’) | ||
| Environmental Sealing: IP41 | ||
| Light Levels: 0-75,000 Lux (direct sunlight) | ||
SCANNING PERFORMANCE | Scan Pattern: Single scan line | |
| Scan Angle Horizontal: 30° | ||
| Print Contrast: 20% minimum reflectance difference | ||
| Pitch, Skew: 60°, 60° | ||
| Decode Capability: Reads standard 1D and GS1 DataBar symbologies | ||
| WARRANTY | Warranty: 5-year factory warranty |
