Physical Characteristic | Dimensions: 152(H)×75.9(W)×12.8(T) | |
Weight: 227g | ||
Display: 5.2 inch, 1920×1080(FHD) | ||
Touch Panel: Multi-touch panel, gloves and wet hands supported | ||
Power: Half-Removable 3.8V 4500mAh, li-ion rechargeable battery | ||
Expansion Slot: Micro SD Card, 128GB SDHC compatible | ||
Notification: Sound, Vibrator, LED indicator | ||
Keypad: volume +, volume -, Power button, Scan button×2, Home button | ||
Voice & Audio: Built-in loudspeaker, built-in microphone | ||
User Environment | Operating Temp: -20 ℃~+50 ℃ | |
Storage Temp: -40℃ to +50℃ (Battery included) -40℃ to +70℃ (Battery excluded) | ||
Humidity: 5% to 95% RH non-condensing | ||
Drop Specification: Multiple 5 ft./1.5m drops to Mable across the operating temperature range | ||
Tumble Specification: 1,000 1.64 ft./0.5 m tumbles (equivalent to 2,000 drops) | ||
Sealing: IP67 per IEC sealing specifications | ||
ESD: ±15kV Air discharge, ±8kV direct discharge | ||
Performance Characteristics | Operating System: Android 9.0(GMS) | |
Memory: 4GB+64GB (4GB+32GB compatible) | ||
Developing Environment | Operating System: Android 9.0(GMS) | |
Language: Java | ||
Tool: Eclipse / Android Studio | ||
Data Capture | Scan Engine: X3 MR: Middle range 1D/2D imaging engine N6603/N6703: Standard range 1D/2D imaging engine | |
Camera: Front: 5MP Phase Direction Auto Focus Rear: 13MP Auto Focus | ||
NFC: Support ISO15693, ISO14443A/B(without encryption protocol), ISO14443A tag with encryption protocol(Mifare one S50,S70 and its compatible cards); Support NFC protocol and ID certificates. | ||
Connectivity | WLAN: IEEE 802.11a/b/g/n/ac(2.4G/5G dual-frequency WIFI) | |
WWAN: 2G: 850/900/1800/1900MHz 3G: B1/B2/B5/B8/B34/B39/BC0 4G: B1/B3/B7/B38/B39/B40/B41 | ||
Bluetooth: Bluetooth 4.2 (Support BLE) | ||
GNSS: GPS, Beidou, GLONASS(Three in one) | ||
Platforming | SEUIC MDM, Standard Android SDK, Wavelink/SOTI for Android |
